Name: H440-4D - Cerwin Vega - HED series 440W 4 Channel Amplifier
SKU: H440.4D
Availability: OutOfStock

H440-4D – Cerwin Vega – HED series 440W 4 Channel Amplifier

R8049,00 Incl. Vat

Out of stock

SKU: H440.4D Categories: Cerwin Vega, HED

Pay over 3 EQUAL zero-interest instalments of R2683,00 with PayJustNow.
Find out how...

HOW IT WORKS

PayJustNow allows you to pay for your purchase over 3 payments with 0% interest and no fees. Pay a third at checkout and you get your goods as if you have paid in full. The remaining two instalments are debited on your specified instalment date.

Browse online or in-store and proceed to check-out

Choose PayJustNow as your payment method

Create your account and get an instant approval decision

Complete your transaction

WHAT YOU WILL NEED

BE OVER 18
YEARS OLD

BE AN SA
RESIDENT

HAVE A DEBIT OR
CREDIT CARD

HAVE A VALID
EMAIL ADDRESS

0% INTEREST. 3 PAYMENTS. NO STRESS.

WHY PAY ANY OTHER WAY?

Description

Additional information

Weight	1 kg

Overview

2 Channel Full Range Digital Amplifier. 200W x 2CH @ 1Ω / 125W x 2CH @ 2Ω / 80W x 2CH @ 4Ω RMS Power Output. 400W x 1CH @ 2Ω / 250W x 1CH @ 2Ω RMS Bridged Power Output. Input Sensitivity: 0.2-10 Volt. Selectable X-Over: LPF / FULL / HPF. Crossover Filter : 50-500Hz, 12dB Per Octave Slope. Frequency Response: 10-33KHz. Signal to Noise Ratio: > 90dB. Overall Operation Efficiency: >84%. Selectable REM / VOX / DC Turn On Modes. Bass Boost: 0 – 18dB.

Features:

2 Channel Full Range Digital Amplifier
200W x 2CH @ 1Ω / 125W x 2CH @ 2Ω / 80W x 2CH @ 4Ω RMS Power Output
400W x 1CH @ 2Ω / 250W x 1CH @ 2Ω RMS Bridged Power Output
Input Sensitivity: 0.2-10 Volt
Selectable X-Over: LPF / FULL / HPF
Crossover Filter : 50-500Hz, 12dB Per Octave Slope
Frequency Response: 10-33KHz
Signal to Noise Ratio: > 90dB
Overall Operation Efficiency: >84%
Selectable REM / VOX / DC Turn On Modes
Bass Boost: 0 – 18dB
Working Status Indicators: Power/Protection
Gain Input Sensitivity Clipping Indicators
Full Range IR Chipset Digital Circuit Design
DirectFET Power Mosfet Output Stage
Compact Size for Easy Installation
SMD Technology on 4 Layers FR4 PC Board
Dimensions: 7.1” x 6.3” x 1.9” / 179.5 x 160 x 48.3 mm

Specifications

Amplifier2 ChannelRMS Power (1Ω)200W x 2CHRMS Power(2Ω)125W x 2CHRMS Power (4Ω)80W x 2CHTopologyFull Range Class-DFrequency Response10-33KHzPower Supply12-14.4VPower Supply (Threshold)8.4V-16.5VIdle Current0.5ADistortion – THD (1KHz@4Ω)<0.3%Distortion – S/N Ratio (A weight @ 1W)>90dBDistortion – S/N Ratio (A weight @ FP)-88dBaInput Sensitivity High0.3V- 8.5VInput Impedance – Low Input Level22KΩInput Impedance – High Input LevelN/AOutput Impedance1ΩDamping Factor (50Hz@4Ω)>100Bandwidth (-3dB)20-30kHzCrossover (-12 dB/ Oct) Variable High-Pass50Hz-500HzCrossover (-12 dB/ Oct) Variable Low-Pass50Hz-500HzFUSE Ratings – ATC30Ax2Dimension – Length x Width x Height – Inches(mm)9” x 6.3” x 1.9” (229.5 x 160 x 48.3 mm)
